HPC100 High Pressure Compressor

I'm Online Chat Now

HPC100 High Pressure Compressor

HPC100 High Pressure Compressor
HPC100 High Pressure Compressor

Large Image :  HPC100 High Pressure Compressor

Product Details:

Brand Name: J&M
Certification: CE, CCS
Model Number: HPC100

Payment & Shipping Terms:

Minimum Order Quantity: 1
Delivery Time: 30
Detailed Product Description
Frequency: 2.2Kw Filling Time: 6.8L 300bar/21min 12L 200bar/25min
Displacement: 100L/min – 6m³/h – 3,5 CFM Stage: Four Stage Compressed
IP Grade: IP55 Noise: < 78 DB(A)
N.W: 44KG
High Light:

manual hand pump


fire extinguisher cylinder


HPC100 High Pressure Compressor For Air and Breathing Air Compression



技术参数(technical) HPC100
Model number HPC100/EM HPC100 /ET HPC100 /SH

cooling air ,

lubricating oil ,

standard compressor)

(cooling ,

Lubricating Oil,

Standard compressor )

(cooling ,

lubricating oil ,

standard compressor )


single phase electric motor 220v

three phase electric motor 380v


gasoline engine

frequency 2.2 Kw 2.2 Kw 5.5 HP

full load current

14A (230V-50/60Hz) 5A (380V-50/60Hz) /
filling time

6.8L 300bar/21min

12L 200bar/25min

6.8L 300bar/20.4min

12L 200bar/24min

6.8L 300bar/20.4min

12L 200bar/24min

displacement 100L/min – 6m³/h – 3,5 CFM

working pressure

225 Bar / 3300 Psi

300 Bar / 4300 Psi

stage four stage compressed
medium air ,Notrogen ,natural gas ,others
intake temperature range 5~45℃

operation temperature range


cooling air







motor speed

2840r/min /

IP Grade

IP55 IP55 /

lubricating filling amount

300 cc (0.3 L) / 10 FL. OZ.
lubricating oil special oil for air compressor /BS750 us Rui fu dedicated food grade oil
master speed 2300r/min 2800r/min 2800r/min
noise < 78 dB(A)
N.W 44 Kg
Size 58×40×41 cm 76×34×47 cm
oil water separator the last stage of oil-water separator
filter activated carbon and molecular sieve filter

breathing air standard
